• Weaving type：plain，twill，dutch，crimped.
• Mesh count：1 to 350 mesh. 200*1800 mesh
• Stock Size：


  Mesh Size	Wire Diameter
  4.2mesh	1mm
  16mesh	0.18mm
  60mesh	0.18mm
  80x70mesh	0.177mm
  80mesh	0.12mm
  150mesh	0.04mm
  200mesh	0.05mm
  300mesh	0.035mm

Some characteristics of Monel 400 wire cloth which dictate its wide use are:

• Solid solution nickel-copper alloy.
• At or below room temperature, it is somewhat-magnetic when annealed.
• Above room temperature, it is non-magnetic (depending on composition impurities) when annealed.
• Withstands outdoor exposure without rusting; great for use in marine and seawater settings.
• Excellent corrosion resistance in broad range of industrial and chemical settings.
• Good for use in hydrochloric acid; great for use against pitting & crevice corrosion in chlorides.
• Excellent for use against chloride stress corrosion cracking.
• Not to be used in phosphoric or nitric acid.
• Max operating temperature of ~1000°F.
• Can be cut, formed, and welded.

Monel 400 wire cloth is principally used in aerospace, chemical, brackish water, seawater, and power generation applications given its superior corrosion resistance properties. Additional industries and applications which commonly use Сплав 400 wire cloth include:

• Boiling
• Commercial Cooking
• Desalination
• Dyeing
• Electrical Components
• Heat Exchangers
• Фильтрация жидкостей и разделение частиц
• Oil Field & Refinery
• Water Heaters
